Overview
Drying Moisture Analyzer is a new product that integrates Electronic Balance technology, halogen radiation technology and temperature control technology of strain equilibrate. It is small in size, perfect in function, easy to use, sturdy and durable. Under the control of a single-chip microcomputer, it has various functions such as weighing calibrate, temperature and time setting, manual automatic heating selection, adjustable display parameters, and a buzzer prompt for the end of heating. It can be connected to an RS232 serial port printer or computer to output 8 parameters and 4 output modes. The instrument works fast and can generally complete the test in a few minutes.
Features
1. Compact size, perfect function, easy to use, sturdy and durable;
2. Under the control of a single-chip microcomputer, it has various functions such as weighing and calibrating, temperature and time setting, manual automatic heating selection, adjustable display parameters, and a buzzer prompt for the end of heating;
3. It can be connected to an RS232 serial printer or computer to output 8 parameters and 4 output modes.
4. Work quickly, usually completing the test in a few minutes.
5. Moisture readability is 0.01% and Moisture Precision is +/- 0.2%.
Principle
Drying Moisture Analyzer combines Electronic Balance technology of strain equilibrate, halogen radiation technology and temperature control technology to realize moisture determination through program control. Under the control of a single-chip microcomputer, the instrument automatically or manually heats the sample, using a halogen tube as the heating source. Temperature range from room temperature to 160 ° C, Timer Range 0 to 120 minutes, by weighing calibrate and parameter adjustment, rapid measurement of sample Moisture content.
Applications
Food, grain, chemical industry
Steps
1. Weighing and calibrating;
2. Set the temperature and heating time.
3. Select manual or automatic heating mode.
4. Start the heating test.
5. After the heating end buzzer prompts, read or output the parameters.
Notice
• Power supply voltage 220V/50Hz before use;
• Temperature range should not exceed 160 ℃;
• Timer Range is set within 0 to 120 minutes;
• Select the appropriate heating mode according to the characteristics of the sample.
• Confirm RS232 interface compatibility when connecting external devices.
