Overview
The NIRUN NTV-HAP2 Digital Viscometer is a digital display device with a 7-inch wide Touchscreen with rich display information and convenient operation interface. It supports a variety of viscosity units and automatic conversion functions for a wide range of fluid measurement applications.
Features
1.7 inch wide Touchscreen, easy to operate, rich display information
2. Optional DV data collection and program control software can measure rheological characteristics, and the screen can directly display rheological Linear dispersion
3. Display shear rate and shear stress metrics
4. Anti-static shell, metal lifting rod design
5. Built-in RTD Temperature Probe
6. ARM chip processor, faster data processing speed
7. Durable new small shaft design
8. Powerful human-machine interaction interface
9. Gigabit network port data communication transmission, fast and reliable data transmission
10. Support external U disk data storage; single point, continuous, timing three storage methods are optional
11. Password protection temperature and viscosity correction factor, allowing users to correct temperature and viscosity correction factor on the premise of reliable and accurate data
12. Support infinitely variable speed measurement viscosity, input any one speed, directly reflect the full scale under each rotor, convenient for users to select test conditions
13. Automatic conversion of dynamic viscosity and kinematic viscosity
14. Any exchange of various viscosity units
15. Interchange of a variety of user-friendly operation styles
16. Random comes with powerful operation wizard help
17. The viscosity value shows continuous change
18. There is an alarm sound beyond the measurement range
19. Computer full-scale linear correction
20. AC Power Adapter 100V-240V, good anti-interference
Principle
The Viscometer calculates the viscosity value by measuring the resistance of the fluid to the rotor by swirling/spinning the rotor in the fluid. The built-in ARM chip processes data quickly and supports stepless speed control, ensuring accuracy and flexibility in measurement.
Applications
Glue, latex, solvent adhesives, polymer solutions, petroleum, paints, solvents, cosmetics, milk products, medicines, fruit juices
Steps
1. Connect the power supply and turn it on.
2. Select the rotor and install it
3. Set measurement parameters such as speed and temperature
4. Place the sample in the measurement position
5. Start the measurement and observe the display data
6. Save data or export results as needed
Notice
- Power frequency within AC100-240V range
- Check whether the rotor is in good condition before use
- Avoid operating beyond the measurement range to prevent alarm
- Periodically calibrate equipment to ensure accuracy
- Please follow the relevant guidelines when using the optional accessories
