Overview
XSP-8C Series Binocular Bio-Microscope is a TEELEN brand product, which is widely used in biology, histology, chemistry and other research institutes and school laboratory teaching. It adopts binocular lens barrel and electric Illuminant lighting, and can choose phase contrast, dark field, polarizing and other accessories to adapt to different user requirements.
Features
1. Hinged binocular head, adjustable pupil spacing of 55-75mm, 30 ° tilt, 360 ° turn
2.Double-decked mechanical stage, size 140X155mm, X-Y direction moving range 70X50mm
3. Variable light bar φ 2-φ 30mm with φ 32 color filter
4.N.A.1.25 Abbe condenser
5. Coarse fretting coaxial focusing, range 30mm, accuracy 0.002mm
6. A variety of Illuminants available: 6V/20W halogen lamp, 20W incandescent lamp, 1W LED lamp, rechargeable LED lamp
7. Total magnification 40X~ 1600X
8. Can be expanded to computer or digital type to support image analysis and processing
Principle
The XSP-8CA-V and XSP-8CA-C models combine photoelectric conversion and computerized image processing technology to observe biological images on a display and perform map analysis.
Applications
Biology, histology, chemistry, research institutes, school laboratories, teaching, professional research, routine inspection
Steps
1. Choose the appropriate objective and eyepiece combination according to the sample
2. Adjust the pupil distance and tilt angle of the binocular tube
3. Turn on Illuminant and adjust luminance
4. Place the sample on the stage
5. Use coarse fretting coaxial focusing mechanism for focusing
6. Move the stage to select the observation area
7. For image analysis, connect to a computer system for operation
Notice
• When using 100X oil mirror, you need to add mirror oil drip.
• Illuminant luminance adjustment to avoid damage to the sample
• Optical inspection parts regularly to maintain imagery mass
• Avoid colliding with the objective lens when moving the stage
• Power should be turned off if not used for a long time
