TEELEN CFM-200 Fluorescence Microscope Large Field Flat Field Color difference

Name: TEELEN CFM-200 Fluorescence Microscope Large Field Flat Field Color difference
Brand: Teelen
SKU: NB025478

Please contact customer service

It adopts coaxial focusing mechanism with coarse fretting, with a fretting grid value of 2 μ m, equipped with 100W high voltage mercury lamp fluorescent epiphany illumination and 6V 20W halogen lamp transmission illumination, and supports B excitation light band 420~ 485nm and G excitation light band 460~ 550nm.

Model

CFM-200

Get Quote

Category : Microscope

Brand : Teelen

SKU : NB025478

Service :The delivery and service By NBCLab.Com

Overview

CFM-200 series epiphany Fluorescence Microscope is suitable for fluorescence microscopy and transmission field of view observation. It is a satisfactory instrument for scientific research and can be used by scientific research, universities and other departments.

Features

1. Equipped with large field of view eyepiece and flat field color difference and fluorescent objective, the field of view is large and clear 2. Coarse fretting coaxial focusing mechanism, coarse elastic adjustable, with locking and limit device, fretting grid value: 2μm 3. Transmission lighting adopts 6V 20W halogen lamp, the luminance is adjustable; fluorescent epiphany lighting adopts 100W high voltage mercury lamp, external power box

Principle

The microscope uses an epifluorescence device, provides an Excitation light source through a mercury lamp light box, and selects a specific excitation light band (B excitation light band: 420~ 485nm, G excitation light band: 460~ 550nm) with a fluorescent filter set to realize the observation of fluorescent samples. At the same time, it is equipped with a transmission illumination system to perform conventional transmission field observation.

Applications

Scientific research, universities

eyepiece
Large field of view WF10X (Φ 18mm)
objective lens
Eliminate color difference 4X/0.10; eliminate color difference 10X/0.25; eliminate color difference 100X/1.25 (spring, oil); fluorescent objective 20X/0.65
Eyepiece tube
Triple eyepiece (tilted 30 °)
Focusing mechanism
Coaxial focusing coarse fretting, with locking and limit device, fretting grid value: 2μm
converter
Four holes (inward ball positioning)
stage
Double-decked mechanical mobile (Size: 135 * 125mm, moving Range: 75 * 35mm)
Abbe condenser
N.A.1.25 can be lifted up and down
Color filter
Blue filter
collector
For halogen lamps
Illuminant
6V 20W halogen lamp, adjustable luminance
Dropper fluorescent device
Mercury lamp box 100W/DC; Power box: AC: 110V or 220V; Fluorescence filter group B excitation optical band: 420~ 485nm; Fluorescence filter group G excitation optical band: 460~ 550nm

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
