Overview
The IWAVE WG68 three-angle glossmeter can complete multi-angle measurement with one click, and can complete three-angle measurement at the same time in one operation. The measurement light Incident angle conforms to the three measurement light Incident angles specified in ISO 2813, and the three incident angles of the mirror-facing glossmeter are 20 °, 60 °, and 85 ° respectively.
Features
1. Multi-angle one-click measurement: one operation can complete the measurement of three angles at the same time;
2. Optional angle mode: Measurement Angles or angle combination can be selected according to user needs;
3. Glossiness data of standard samples can be entered manually;
4. Humanized design, good human-machine interaction interface;
5. Trigonometry can store 50,000 test records, the storage structure is: 100 master standards, each master standard can store 500 sets of test data;
6. Data browsing and viewing function;
7. This machine has automatic shutdown function, low battery prompt function, and full storage data space prompt function;
8. USB Communication interface, can communicate with PC; 9. PC Glossiness software, can expand more functions.
Principle
Incident angles of 20 °, 60 °, 85 ° for gloss measurement in accordance with ISO 2813 standards.
Applications
Paints Coatings, Decoration Materials, Building Materials, Plastic Materials, Bamboo and Wood Products, Ceramic Products, Leather Products, Film Paper, Printing inks, Automobile Maintenance, Molding Molds, Metal Products
Standards
ISO2813、ISO7668、ASTM D523、ASTM D2457、GB/T 9754、GB/T 13891、GB/T 7706、GB/T 8807
Steps
1. Use standard plates for instrument calibrating;
2. Select Measurement Angles or Angle Combination;
3. Manual measurement, automatic measurement, single measurement or average measurement;
4. Communicate with PC via USB interface.
Notice
• Standard board refers to a working standard device matched with glossmeter for instrument calibrating;
• The instrument should be used to avoid strong electromagnetic interference, not in an environment with Humidity greater than 85% and condensation;
• In order to avoid affecting the accuracy of the instrument and increasing the difficulty of maintenance, please do not disassemble the instrument without permission;
• If the instrument is damaged due to disassembly or incorrect use, please be responsible for it.
