Overview
SANFA LHP-300EL Constant Temperature and Humidity Incubator is a device with precise temperature and humidity control system, which can provide various environment simulation conditions required for industrial research and biotechnology testing. It is widely used in sterility testing, stability inspection, and raw material performance and product Encasement life testing of industrial products.
Features
1. Microcomputer LCD temperature and humidity controller, accurate and reliable temperature and humidity control, with over-temperature, leakage, power failure, Sensor fault alarm function.
2. Adopting a fluorine-free design, it offers high efficiency, low energy consumption, uniform temperature distribution, and long service life.
3. Mirror stainless steel liner, four corners and half arc design, easy to clean, adjustable shelf spacing.
4. High Accuracy and large capacity humidity generator, humidity control occurs quickly, high accuracy and small fluctuation.
5. The box door is equipped with an observation window, and the box is equipped with lighting, which is convenient for observing the foster.
6. With over temperature, Sensor failure, leakage, shutdown protection, door opening protection, water shortage alarm, call recovery function.
7. Independent temperature limit alarm system, automatic interruption beyond the limit to ensure experimental safety (optional).
8. Can be connected to a printer or equipped with an RS-485 interface to record changes in temperature and humidity parameters (optional).
9. The left side of the box is equipped with a test hole, which is convenient for experimental operation and temperature measurement (optional).
10. Equipped with built-in humidifier (optional).
11. Smart Touchscreen controller, programmable control, humidity fluctuation +/- 5% RH, built-in ultrasonic humidifier, optional RS-485 interface and embedded printer.
Principle
The Constant Temperature and Humidity Incubator precisely adjusts the temperature and humidity through a microcomputer controller, uses environmentally friendly refrigerants and fluorine-free design to achieve efficient cooling, and the built-in humidity generator quickly stabilizes the humidity.
Applications
Spinning & weaving, Food processing and other aseptic test, stability inspection, industrial product raw material performance test, product Encasement life test
Steps
Connect the power supply (220V 50Hz).
2. Set the required temperature (range -10 to 85 ° C) and humidity (range 35 to 95% RH) through the smart Touchscreen controller.
3. Adjust the shelf spacing and place the foster.
4. Start the equipment, monitor the temperature and humidity parameters, and optionally record data.
5. After the experiment is completed, turn off the power and clean the liner.
Notice
The Ambient Temperature should be kept at 5~ 35 ℃.
Avoid over-temperature operation and pay attention to the status of the temperature limit alarm system.
Regularly check Sensor and Humidifier functions to ensure accuracy and safety.
Use a soft cloth when cleaning to avoid damage to the mirror stainless steel liner.
Optional functions such as RS-485 interface, printer, etc. need to be installed and used according to the instructions.
