RDS 10 #3/8 Forming Applicator Rod Wet glue coating bar 22.9μm film thickness 30cm application width

Name: RDS 10 #3/8 Forming Applicator Rod Wet glue coating bar 22.9μm film thickness 30cm application width
Brand: RDS
SKU: NB033703
Price: 165.0 USD
Availability: PreOrder

$ 165.00Ex works

The formed pRoduction process ensures that the film is uniform, the film thickness is 22.9μm, the application width is 300mm, which is suitable for low viscosity glue experiment, and the material is wear-resistant stainless steel to prolong the service life.

Model

Get Quote

Category : Coating Rod

Brand : RDS

SKU : NB033703

Service :The delivery and service By NBCLab.Com

Overview

RDS 10 #3/8 "forming Applicator rod is a special tool for experimental films such as low viscosity glue and thermal glue. The film thickness is 22.9μm and the application width is 30cm. The product is made of high-quality wear-resistant stainless steel, and the process is molding. The 3/8 diameter design is in line with domestic users' habits, and it is one of the hot selection series.

Features

1. Made of high-quality wear-resistant stainless steel to ensure durability 2. Molding process design, uniform film 3.3/8 diameter specifications meet the usage habits of domestic users 4. Available in a variety of diameter options (3/8 ", 1/2", 1/4 ") 5. Spreader application width up to 300mm

Principle

Applicator rod is formed by a production process, using a low viscosity glue or heat sensitive adhesive Spreader uniformly on the surface of the substrate to form a wet-film coating with a thickness of 22.9μm.

Specifications

Production process: formed, wet film thickness: 22.9μm, diameter: 9.52mm, total length: 400mm, application width: 300mm, material: stainless steel

Production process
formed
wet film thickness
22.9μm
rod diameter
9.52mm
Total length
400mm
application width
300mm
material
stainless steel
