Overview
US RDS 40 #3/8\ "thin layer plate coating applicator is a laboratory manual Applicator rod with a diameter of 9.5mm, which can be equipped with automatic film on a small laboratory Spreader. The coating applicator has good Abrasion Resistance and is suitable for high abrasion experimental film proofing. The film thickness is 91.4 μm and the accuracy is up to 0.1 μm. It can be used for multi-layer Spreader. It is suitable for paper, Glass and film substrates.
Features
1. Adopt formed production process
2.Wet film thickness 91.4 μm, accuracy up to 0.1 μm
3.Diameter 9.52mm, total length 400mm, application width 300mm
4. Stainless steel, Abrasion Resistance
5. Support manual and automatic filming
6. Suitable for Multi-layer Spreader and High abrasion experiments
Principle
Applicator rod formed by the production process, the use of manual or mounted on a small Spreader Spreader operation, using its precise bar structure and thickness control, forming a uniform film layer on the substrate surface.
Applications
Paper film, Glass film, Film film, Laboratory film proofing
Steps
1. Spreader substrate (paper, Glass or film)
2. Applicator rod manually or mounted on a small Spreader
3. Spreader operation
4. Multi-layer Spreader as required
Notice
• Ensure that the substrate surface is clean and flat before use
• Spreaders maintain uniform speed and pressure
• Regularly check Applicator rod abrasion
• Suitable for use in laboratory environments
