Overview
The Fungilab EVO EXPERT R is a rotational viscometer with High Accuracy measurement and versatile Data analysis capabilities. The instrument supports dynamic viscosity and kinematic viscosity measurement. It is equipped with a touch display and multiple program Measurement modes for viscosity analysis of various fluid samples.
Features
1. Rotation speed, viscosity, sample temperature, shear stress, rotor, full scale percentage, shear rate and density and other data display
2. Can measure dynamic viscosity and kinematic viscosity
3. With SI unit system and CGS unit conversion function
4. Support Multi-step Program Measurement mode, can store 9 programs
5. Provide TTT and TTS Measurement modes and multiple data models
6. With Self-check function and sound and light alarm reminder
7. Automatically calculate the maximum range under the combination of rotor and Rotation speed
8. Support user-defined viscosity and temperature calibrating
9. Available in 10 languages
Principle
The instrument generates shear force by the rotor swirling/spinning in the sample, and measures the resistance of the sample to calculate the viscosity value. The matching PT100 temperature probe monitors the sample temperature in real time, and realizes accurate shear rate adjustment through 2600 gear Rotation speed control.
Applications
Chemical, pharmaceutical, food, coatings, petroleum
Standards
FDA 21CFR Section 11
Steps
1. Install the rotor and protective legs
2. Connect PT100 temperature probe
3. Measurement mode and parameter selection
4. Start measurement and record data
5. Use FDB software to analyze the results
Notice
• Shear stress and shear rate need to be matched with a coaxial rotor to display
• Enter the sample density value in advance before measuring kinematic viscosity
• Instrument leveling is required before use
• Choose the right rotor and adapter for different viscosity ranges
• Regularly calibrated to ensure Measurement accuracy
