Overview
JFL-B45S type Glossiness Meter is a small hole Gloss Meter produced by JFL brand. It is a High Accuracy and miniaturized instrument manufactured in accordance with ASTM-C346, ASTM-D2457, GB/T3295, GB8807 standards. It is suitable for Plastic film, ceramic, enamel and other surface mirror to Glossiness value measurement.
Features
1. High Accuracy measurement, Indication Error less than 1.2GU
2. Miniaturized design, easy to carry and use
3. Meet the national Measurement verification regulations JJG 696 Glossiness Meter standard
4. Display range 0.0-199 Gloss unit (GS)
5. Stability is high, 0.4GU
6. The measurement window size is 1.5 × 2 mm elliptical
7. Operating voltage is low, only one AA battery (1.5V)
8. Compact instrument size, 114 × 35 × 64mm
Principle
The Glossiness Meter is based on the principle of mirror reflection and evaluates the Gloss performance of a material by measuring the Glossiness value of the light reflected by the surface.
Applications
Plastic film, ceramic, enamel
Standards
ASTM-C346, ASTM-D2457, GB/T3295, GB8807, JJG 696 Glossiness Meter Standard
Notice
• Ensure that the measurement surface is clean and avoid stains affecting the accuracy
• Check the battery level before use to ensure normal operation
• Avoid use in bright light or extreme environments to prevent measurement errors
Periodically calibrate instruments to maintain measurement accuracy
