Overview
SANFA CHP-160Q Co2 incubator is a professional instrument specially designed for cell, tissue and bacterial fostering. It adopts air-nested Heating mode, has a volume of 160L, and is equipped with an intelligent Control system, which can precisely control parameters such as temperature and CO2 concentration.
Features
1. Microcomputer intelligent controller with temperature control, CO2 gas, door temperature, water level, UV Lamp, timing control and over-temperature, water level, Safety protection, alarm function.
2. The CO2 inlet is equipped with a microbial effective Filter, which penetrates 99.99% of the 0.3um diameter particles, effectively penetrating bacteria and dust.
3. Built-in ultraviolet sterilization lamp, which can regularly disinfect the box to kill floating bacteria in the circulating air and humidifying disc water vapor to prevent pollution.
4. Glass door heating function to prevent condensation, reduce the risk of microbial contamination.
5. Antibacterial stainless steel liner, four-corner arc design, easy to clean, adjustable shelf.
6. The upgraded touch color screen intelligent temperature control instrument supports programmable, running Linear dispersion display, temperature, Humidity, CO2 concentration three groups Linear dispersion view and abnormal alarm switch functions, temperature control is more accurate, CO2 concentration is more stable.
7. Optional RS-485 interface, connecting printer and computer to record temperature parameters.
Principle
The Co2 incubator precisely adjusts the temperature, CO2 concentration and Humidity in the box through the intelligent controller, and adopts the gas sleeve Heating mode to keep the temperature stable. The CO2 gas enters the box after being purified by the microbial Filter, the infrared Sensor monitors the CO2 concentration, and the UV Lamp regularly disinfects the internal environment to ensure that the cell fostering conditions are constant and pollution-free.
Applications
Microbiology, agricultural science, tissue and cell fostering, AIDS research, oncology research, heart disease research, virus propagation, bacterial fostering, genetic engineering, testtube babies, cloning technology, immunology
Steps
1. Turn on the power supply and set the Ambient Temperature within the range of + 5~ 35 ℃.
2. Use the intelligent controller to set the Temperature range (RT + 5~ 60 ℃), CO2 control range (0~ 20%) and Miscellaneous parameters.
3. Start the CO2 intake system to ensure the normal operation of the Microbial Filter.
4. Turn on the UV sterilization lamp for regular disinfection as needed.
5. Place the foster on the shelf and close the box door.
6. Monitor the running status, check the temperature, Humidity, CO2 concentration Linear dispersion through the controller, and deal with the alarm in time.
Notice
• Ensure that the Ambient Temperature is in the range of + 5~ 35 ° C to avoid extreme conditions affecting the performance.
• Regularly check the CO2 Intake Filter and UV Lamp to ensure they work effectively.
• Pay attention to the heating function of the box door to prevent the accumulation of condensate.
• Use appropriate methods when cleaning the liner to avoid damage to the antibacterial stainless steel surface.
• In case of over-temperature, abnormal water level and other alarms during use, check immediately and take safety measures.
• Power supply voltage must be 220V 50Hz to avoid equipment failure due to mismatch.
