Overview
OSP-120/400 coating rod is a formed film tool with a wet film thickness of 120 microns, a diameter of 10mm, a total length of 400mm, and an application width of 300mm. The product is equipped with a handle part of 50mm at both ends and is made of 304 stainless steel. Users can choose the appropriate width specification according to the actual Spreader needs to reduce waste and save costs.
Features
1. formed production process to ensure uniform film
2. Precise 120 micron wet film thickness control
3.10Mm diameter design for easy operation
4. Equipped with 50mm handles at each end for comfortable holding
5.304 stainless steel material, durable and easy to clean
6. Various application widths are available to meet different application needs
Principle
The OSP-120/400 coating rod adopts the formed Working Principle. By precisely controlling the gap between the rod body and the substrate, the Coating is evenly squeezed during movement to form a wet-film with a thickness of 120 microns. The smooth surface of the stainless steel rod body ensures that the Coating is evenly distributed for a consistent Spreader effect.
Applications
Lab Spreaders, Sample prepatives, Coating tests, Film prepatives
Steps
1. Select the appropriate application width coating rod
2. Coating evenly on one end of the substrate
3. Handle both ends of the coating rod and pull at a constant speed
4. Keep the coating rod in parallel contact with the substrate surface
5. Clean coating rod after finishing Spreader
Notice
• Ensure that the surface of the coating rod is clean and free of contamination before use
• Spreader at a constant speed to achieve uniform film thickness
• Avoid scratching the surface of the coating rod with hard objects
• Clean immediately after use to prevent Coating curing
• Avoid collision with Miscellaneous hard objects during storage
