Overview
FANGZHOU FZ-833 is a PH Electrode with lead-free Glass housing, BNC connector and 1 meter cable. The Electrode is suitable for pH value measurement. Measurement range is 0~ 12pH. Operating temperature range is 0~ 100 ℃.
Features
1. Measurement parameter is pH value, range 0~ 12pH
2. Temperature range 0~ 100 ℃, equipped with NTC 30KΩ temperature sensor
3. Glass film is made of HF material, film Impedance < 400MΩ
4. The liquid network part is designed for ceramic core
5. Reference type is silver ion trap, electrolysis solution is 3M KCL
6. Shell material is Lead-free Glass
7. Electrode size φ 12 * 120mm, connector is BNC/1m
Principle
The PH Electrode senses the concentration of hydrogen ions in the solution through the Glass film, generating a potential difference, and combines the NTC temperature sensor for temperature compensation to provide a stable reference potential through the reference system (silver ion trapping trap and 3M KCL electrolysis solution) for accurate measurement of PH value.
Applications
Water quality monitoring, laboratory analysis, industrial process control, environment testing
Standards
Lead-free environmental standards
Steps
1. Connect the Electrode BNC connector to the corresponding measuring instrument
2. Electrode immersion in the solution to be tested
3. Record the PH value after waiting for the reading to stabilize
4. Clean Electrode After Use and Store Properly
Notice
• Avoid collision of Electrode Glass film with hard objects
• It should be cleaned in time after use to prevent pollution
• When not in use for a long time, it should be stored according to the instructions
• Ensure sufficient reference electrolysis solution
• Use within the specified Temperature range
