Overview
FANGZHOU FZ-861 is a PH Electrode with Lead-free Glass housing and PHY Glass film design for pH value measurement. The Electrode Measurement range is 1~ 13pH, Operating temperature range is 0~ 130 ℃, equipped with BNC connector and 1 meter cable.
Features
1. Using PHY Glass Film, Film Impedance Less Than 500MΩ
2. Equipped with porous PTFE fluid
3. Using silver ion trap reference type
4. Use 3M KCL gel reference electrolysis solution
5. Lead-free Glass Shell Material
6. Electrode size is φ 12 * 120mm
7. BNC connector with 1 meter cable
Principle
PH Electrode senses the concentration of hydrogen ions in the solution through the Glass membrane, generating a potential difference to measure the PH value. The reference system provides a stable reference potential through the silver ion trapping trap and the 3M KCL gel electrolysis solution, and the porous PTFE liquid complex ensures the ion exchange between the electrolysis solution and the sample solution.
Applications
Water quality monitoring, laboratory analysis, industrial process control, environment monitoring, food testing
Steps
1. Connect the Electrode BNC connector to the pH meter
2. Calibrate with standard buffer solution
3. Electrode immersion in the solution to be tested
4. Record the PH value after waiting for the reading to stabilize
5. Clean Electrode After Use and Store Properly
Notice
• Avoid collision of Electrode Glass film with hard objects
• Wash with deionized water before and after use
• Store with a protective cover when not in use for a long time
• Avoid use in strong corrosion solutions
• Electrode performance and timely replacement
