Overview
KESIONOTS KS-OTS-HD800LA low/high temperature test chamber is an environmental testing equipment suitable for high and low temperature Reliability testing of industrial products. The equipment is used in the fields of electronics and electricians, automobiles and motorcycles, aerospace, marine weapons, colleges and universities and R & D institutions. The inspection performance of product parts and materials under high and low temperature cycle conditions supports product design, improvement, identification and aging tests.
Features
Wide temperature control range: -70 to 150 ° C.
2. High Accuracy Temperature Control: Analysis accuracy +/- 0.1 ℃, control accuracy +/- 1.0 ℃, uniformity +/- 1.0 ℃, fluctuation +/- 0.5 ℃.
3. Rapid temperature change: the heating rate is about 4.0 ° C/min, and the cooling rate is about 1.0 ° C/min.
4. High-quality material: The studio is made of stainless steel, the outer box is high-grade cold plate nano-baking paint, and the thermal insulation material is high temperature and high density chlorine-based formic acid ethyl vinegar foam insulator.
5. Advanced refrigeration system: wind and water-cooled/dual-stage Compressor, optional French "Taikang" or German "BITZER" brand.
6. Multiple protection devices: including no fuse switch, Compressor overload protection, refrigerant high and low voltage protection, ultra-humidity over-temperature protection, fuse and fault warning system.
7. Optional controller: Korean or Japanese "OYO" brand.
8. Standard accessories: viewing window, 50mm test hole, PL box light, Shelf, wet and dry ball gauze.
Principle
The low/high temperature test chamber realizes temperature control through the refrigeration system and heating system, simulating the high temperature and low temperature environment inside the studio. The equipment adopts two-stage Compressor and air and water-cooled refrigeration, combined with accurate temperature sensors and controllers to ensure temperature uniformity and Stability. Reliability tests such as product aging and performance testing.
Applications
Electronics and electricians, automobiles and motorcycles, aerospace, ships and weapons, colleges and universities, R & D institutions
Standards
GB10592-89、GB2423.1、GB2423.2、GJB150.3、GJB150.4、IEC、MIL
Steps
1. Connect power supply: Select 220VAC +/- 10% 50/60Hz or 380VAC +/- 10% 50/60Hz power supply according to specifications.
2. Set parameters: Use the controller to set the required Temperature range and Miscellaneous test conditions.
3. Place the sample: Place the test product in the studio to ensure even distribution.
4. Start the test: run the equipment, monitor temperature changes and performance indicators.
5. End the test: After completing the test, turn off the equipment and remove the sample.
Notice
• Power supply voltage meets equipment requirements to avoid overload.
• Regularly check protective devices, such as fuse-free switches and Compressor overload protection, to ensure safe operation.
• During operation, pay attention to ultra-humidity and over-temperature protection to prevent equipment damage.
• When using accessories such as wet and dry ball gauze, install and maintain correctly according to the instructions.
• During the operation of the equipment, avoid frequent switching to extend the service life.
