Overview
KESIONOTS KS-OTS-HD408LC low/high temperature test chamber (also known as environmental test chamber) is suitable for high temperature and low temperature Reliability test of industrial products, used for electronic and electrical, automobile and motorcycle, aerospace, ship weapons, colleges and universities, R & D institutions and other related products. Components and materials in high temperature, low temperature (alternating) cycle change inspection of various performance indicators to carry out product design, improvement, identification and inspection, such as aging test.
Features
1. Temperature range: -40~ 150 ℃
2. High temperature resolution accuracy: +/- 0.1 ℃
3. Temperature Uniformity: +/- 1.0 ℃
4. High temperature control accuracy: +/- 1.0 ℃
5. Temperature Fluctuation: +/- 0.5 ℃
6. Fast heating rate: Technologies 4.0 ℃/min
7. Stable cooling rate: Technologies 1.0 ℃/min
8. The studio material is stainless steel, and the outer box material is high-grade cold plate nano-paint.
9. The thermal insulation material is made of high temperature and high density chlorine-based formic acid vinegar foam insulator material
10. The refrigeration system can be selected from air and water-cooled/double-stage Compressors
11. Equipped with a variety of protection devices: no fuse switch, Compressor overload protection switch, refrigerant high and low voltage protection switch, ultra-humidity over-temperature protection switch, fuse, fault warning system
12. Complete accessories: viewing window, 50mm test hole, PL box light, Shelf, wet and dry ball gauze
13. The controller system can be selected with Korean or Japanese "OYO" brand
14. The refrigeration system can be selected from the French "Taikang" brand or the German "BITZER" brand.
Principle
The low/high temperature test chamber realizes temperature control through the refrigeration system and heating system. In the aging test such as promoting the deterioration of sulfur rubber, simulate high temperature and low temperature environment changes, and inspect product performance indicators. For example, one day of testing at 70 ° C is theoretically equivalent to 6 months of exposure to the atmosphere.
Applications
Electronics and electricians, automobiles and motorcycles, aerospace, ships and weapons, colleges and universities, R & D institutions
Standards
GB10592-89、GB2423.1、GB2423.2、GJB150.3、GJB150.4、IEC、MIL
Steps
1. Connect power supply: 220VAC +/- 10% 50/60Hz or 380VAC +/- 10% 50/Hz power supply according to specifications
2. Set temperature parameters: Set the required Temperature range through the controller system
3. Place the sample: put the parts or materials of the product to be tested into the studio
4. Start-up test: run equipment for high temperature, low temperature or alternating cycle test
5. Monitoring process: observe the test status through the viewing window and test hole
6. End the test: stop the equipment after reaching the set time or condition, and remove the sample
7. data analytics: inspection sample performance index changes
Notice
• Power supply voltage meets equipment requirements (220VAC +/- 10% or 380VAC +/- 10%)
• Regularly check whether the protection device such as no fuse switch, Compressor overload protection switch is normal
• Avoid running at high temperatures and humidity to prevent triggering the protection system
• Confirm that the studio is clean before use, and no debris will affect the test
• Maintain the refrigeration system to ensure the efficient operation of the Compressor
• Follow relevant safety standards to prevent accidents
