Overview
TR 1202/025 double-channel Fineness Gauge is a TRUIT brand Grindometer that meets GB and ISO standards. The product is made of high-quality wear-resistant and corrosion-resistant alloy steel with a Hardness of 52 +/- 2HRC, with a range of 0~ 25μm and 1.25μm Graduation, and a groove size of 140 × 12.5mm. It is suitable for measurement of a variety of materials.
Features
1. Made of wear-resistant and corrosion-resistant alloy steel, Hardness 52 +/- 2HRC ensures long service life
2. double-channel design, providing two working surfaces
3. A variety of ranges are available, covering the range of 0~ 15, 0~ 25, 0~ 50, 0~ 100, 0~ 150 μm
4. Meet a number of national and international standards
5. Suitable for a variety of industries and material measurement
Principle
Grindometer controls the mass of the product by placing the sample in the trench, observing the particle distribution after scraping with a scraper, and measuring the size and dispersion of the pigment and impurity particles.
Applications
Coatings, lacquer pulp, plastics, inks, paper, Pottery and porcelain, food, cosmetics and other liquids and pulps
Standards
GB/T 1724、GB/T 6753.1、GB/T 13217.3、ISO 1524
Specifications
Scraper material: wear-resistant and corrosion-resistant alloy steel
Hardness: 52 +/- 2HRC
Scraper: upper and lower working surfaces
Range: 0~ 25μm
Graduation: 1.25μm
Number of grooves: 2
Groove size: 140 * 12.5mm
Scraper type: double-channel
