Overview
TRUIT 4-sided Applicator TR 3004/160/4 is a 4-sided Film Applicator for Coating, inks, paints and other experimental manual film proofing. It can also be Moulding on an automatic film machine. It has four film film thicknesses (25, 50, 75, 100 μm), an effective Spreader width of 160mm, and is made of high-quality wear-resistant and corrosion-resistant alloy steel. It can precisely control the wet-film or dry-film thickness to ensure good coating conformity and Repeatability.
Features
1.4-sided design, providing four different film Film thickness options
2. High-quality wear-resistant and corrosion-resistant alloy steel material, strong durability
3. Precise control of wet-film or dry-film thickness
4. Spreader width 160mm, total length 190mm
5. Suitable for manual film and automatic Film Applicator
6. Ensure good coating conformity and Repeatability
Principle
The 4-sided Applicator scrapes the surface of the substrate with coatings, inks or paints through four different height scraper surfaces to form wet-films of different film thicknesses. Each scraper surface corresponds to a specific film thickness specification, and the user can select the appropriate surface for Spreader according to needs to achieve precise control of the coating thickness.
Applications
Coatings, inks, paints experimental film proofing, quality control, research and development tests
Steps
1. Select the appropriate film Film thickness surface
2. Place Applicator on Substrate
3. Push the Applicator evenly manually or through the Automatic Film Applicator
4. After finishing the film, remove the Applicator
Notice
• Ensure Applicator is clean and free of contamination before use
• Spreader should maintain uniform strength and speed
• Clean Applicator Surface After Use
• Avoid prolonged contact with corrosive substances
Store in a drying environment
