RDS 10 #1/2\ "Applicator Rod wire-wound drawdown bar wet film thickness 22.9μm

$ 184.00Ex works

The wet film thickness is 22.9 microns, the application width is 300mm, the stainless steel material is used, the forming Rod is processed by extrusion process, the continuous wire is easy to clean, and the wire-wound drawdown bar is widely used based on traditional principles.

Model

Get Quote

Category : Coating Rod

Brand : RDS

SKU : NB004599

Service :The delivery and service By NBCLab.Com

Overview

The RDS 10 #1/2\ "Applicator rod is a professional Spreader tool with a wet film thickness of 22.9 microns and is available in two types: wire-wound drawdown bar and molding rod. The molding rod is processed by a special extrusion process and has a continuous groove structure; the wire-wound drawdown bar is designed based on the traditional Mayer Rod principle and is more widely used in the industry. The film thickness and accuracy of the same model of the two types are the same, the main difference is Coat Weight.

Features

1. Provide two types of wire-wound drawdown bar and molding rod\ n2. The molding rod adopts a special extrusion process and has a continuous groove structure\ n3. The molding rod is continuous and easy to clean\ n4. The wire-wound drawdown bar is based on the traditional Mayer Rod test principle\ n5. The film thickness and accuracy of the same model are consistent\ n6. Stainless steel material, strong durability

Principle

Wire-wound drawdown bars follow the traditional Mayer Rod test principle and control film thickness by forming a specific gap in the wire wound around the steel rod. The forming bar is formed by a special extrusion process to process continuous grooves on the steel rod for precise Spreader control. Both types can accurately control the wet film thickness of 22.9 microns.

Specifications

Production process: wide-wound\ nwet film thickness: 22.9μm\ ndiameter: 12.7mm\ ntotal length: 400mm\ napplication width: 300mm\ nhand width: 50 + 50mm\ nmaterial: stainless steel\ nsteel wire diameter: 0.25mm

Production process
wire-wound
wet film thickness
22.9μm
rod diameter
12.7mm
Total length
400mm
application width
300mm
Grip Width
50+50mm
material
stainless steel
wire diameter
0.25mm

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
