RDS 20 #1/2 "Applicator Rod Mayer Rods 45.7μm film thickness 30cm application width

Name: RDS 20 #1/2 "Applicator Rod Mayer Rods 45.7μm film thickness 30cm application width
Brand: RDS
SKU: NB004614
Price: 184.0 USD
Availability: PreOrder

$ 184.00Ex works

Film thickness 45.7μm, application width 300mm, stainless steel material, wear and corrosion resistance, suitable for high viscosity or high abrasion test, accuracy up to 0.1 micron.

Model

Get Quote

Category : Coating Rod

Brand : RDS

SKU : NB004614

Service :The delivery and service By NBCLab.Com

Overview

RDS #20 Mayer Rods is a 20 #1/2 "Applicator rod with a film thickness of 45.7μm and an application width of 30cm. The product is divided into two processes: wire-wound and molded. The molded coating rod is a formed coating rod with higher film scale accuracy up to 0.1 microns. It is suitable for industrial users with high accuracy requirements. Made of stainless steel, it has wear resistance and corrosion resistance, especially suitable for high viscosity or high abrasion experiments.

Features

1. Provide wide-wound and molding production process options 2. Molded coating rod film scale accuracy up to 0.1 micron 3. Made of stainless steel, wear and corrosion resistance 4. Suitable for high viscosity or high abrasion experimental environment 5. The application width is 300mm, and the operation range is wide

Principle

RDS #20 Mayer Rods realizes film function through wire-wound or molding process. Wire-wound coating rods control film thickness by winding steel wires; molded coating rods use a formed design to achieve High Accuracy film through precision extrusion process, film scale accuracy up to 0.1 micron, ensuring Spreader uniformity and accuracy.

Specifications

Production process: wire-wound, wet film thickness: 45.7μm, diameter: 12.7mm, total length: 400mm, application width: 300mm, hand width: 50 + 50mm, material: stainless steel, wire diameter: 0.51mm

Production process
wire-wound
wet film thickness
45.7μm
rod diameter
12.7mm
Total length
400mm
application width
300mm
Grip Width
50+50mm
material
stainless steel
wire diameter
0.51mm

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
