RDS 44 #1/2\ "Applicator Rod Mayer Rods wet film thickness 100.6 microns

$ 184.00Ex works

Wire-wound technology, wet film thickness 100.6μm, application width 300mm, through the wire diaMeter of 1.12mm accurate control of film thickness, easy to operate and Repeatability.

Model

Get Quote

Category : Coating Rod

Brand : RDS

SKU : NB004626

Service :The delivery and service By NBCLab.Com

Overview

US RDS #44 Mayer Rods is a coating rod that inherits the principle of "Mayer" rod Spreader, which can be prepared with a specific wet film thickness of 100.6 microns, and the effective application width is 300mm. The molded coating rod adopts a new extrusion process technology, without winding steel wires, and controls the film thickness through the size of the groove.

Features

1. Adopt new extrusion technology, eliminating the need to wrap steel wires. 2. Precise control of film thickness by groove size; 3. Provide dozens of models to choose from, with a wide range of films; 4. Supporting wet-film calculator tool to facilitate user selection.

Principle

Based on the principle of "Mayer" rod Spreader, the wet film thickness is controlled by the size of the groove, and the traditional winding steel wire is not required, and the extrusion process is used.

Specifications

Production process: wire-wound, wet film thickness: 100.6μm, diameter: 12.7mm, total length: 400mm, application width: 300mm, hand width: 50 + 50mm, material: stainless steel, wire diameter: 1.12mm.

Production process
wire-wound
wet film thickness
100.6μm
rod diameter
12.7mm
Total length
400mm
application width
300mm
Grip Width
50+50mm
material
stainless steel
wire diameter
1.12mm
