AMITTARI AC-112BS Coating thickness Gauge split iron-based non-iron-based dual-use

Name: AMITTARI AC-112BS Coating thickness Gauge split iron-based non-iron-based dual-use
Brand: AMITTARI
SKU: NB047736
Price: 520.0 USD
Availability: InStock

$ 520.00Ex works

Supports iron-based and non-iron-based material measurement with accuracy of +/- 1~ 3% or +/- 2.5 µm, provides split Probe for enhanced maneuverability, automatically recognizes matrix materials and remembers calibrated values.

Model

AC-112BS

Get Quote

Category : Coating Thickness Gauge

Brand : AMITTARI

SKU : NB047736

Service :The delivery and service By NBCLab.Com

Overview

The Coating thickness gauge AC-112BS (split) is a widely used, accurate measurement instrument for ferrous and non-ferrous materials. The instrument is equipped with an RS-232C data cable, USB data connection and Bluetooth transfer function. The split design provides multiple Probes for greater measurement mobility.

Features

1. Iron-based and non-iron-based dual-use Coating thickness gauge 2. Single and Continuous Measurement modes available 3. Male/imperial unit conversion, with functions such as manual shutdown, automatic shutdown and undervoltage prompt 4. Automatically remember the calibrated value and automatically identify the material of the tested substrate 5. There is a buzzer prompt tone during operation, and the buzzer does not sound during continuous measurement 6. Use USB data cable output, RS-232C data cable and software to communicate with PC 7. Provide optional configuration Bluetooth BlueTothTM data output selection

Principle

The Coating thickness gauge automatically identifies the substrate material and measures Coating thickness by Probe contacting the measured surface. In measurement, Probe's large contact surface provides better Stability, ensuring continuous and accurate measurement results with strong Repeatability.

Applications

Coating thickness measurement

Steps

1. Measurement mode (single or continuous) 2. Probe contact with the measured surface for measurement 3. Read the measurement results on the display 4. Data can be transferred via USB, RS-232C or Bluetooth

Notice

• Temperature range 0~ 50 ° C (32~ 122 ° F) • Operating Humidity should be less than 80% RH • Powered by 4x1.5V AAA AA AA batteries • The thinnest substrate is 0.3mm/12mil • Minimum convex diameter of 4mm/0.16inch • Minimum concave radius of 25mm/0.98inch • Minimum measurement surface diameter of 6mm/0.24inch

display screen
4-Bit digital backlight LCD
Standard test scope
0~ 1250µm/0~ 50mil (Miscellaneous Measurement Range can be customized)
resolution
0.1 µm (below 100 µm) 1 µm (above 100 µm) 0.1 mil
margin of error
+/- 1 to 3% n or +/- 2.5 µm or 0.1 mil
thinnest matrix
0.3mm / 12mil
minimum convex diameter
4mm / 0.16inch
minimum concave radius
25mm / 0.98inch
minimum measurement surface
Φ6mm / 0.24inch
Measurement mode
Single measurement and continuous measurement
Operating Conditions
Temperature 0~ 50 ° C (32~ 122 ° F); Humidity < 80% RH
power supply
4X1.5V AAA AA batteries
Dimension
140x70x31mm 5.5x2.8x1.2inch
weight
130G (without battery) 4.59oz

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
