Overview
The TL-20 Digital Force Gauge is a general-purpose Portable push-pull load testing instrument launched by HBO, suitable for push-pull load testing, plug-in force testing and failure testing of various products, and can be combined with various machines and fixtures to form a small testing machine for different purposes.
Features
1. Light weight, small size, wider application scenarios
2. LCD display, white backlight, convenient reading
3.5 Units: N, KN, Kgf, lbf, tf are converted to each other
4. Real-time tracking mode, peak hold mode can be switched freely
5. Free setting of upper and lower limits, automatic sound and light alarm
6. Peak hold time can be set (can be set from 0 to 99 seconds)
7. Gravity acceleration value can be set
8. Free setting of automatic shutdown time without operation (0-99 minutes)
9. Feel free to combine various testing devices to make the test more accurate
10. Special Instrument Toolbox, Contains Foam Shockproof Encasement, Easy to Transport, Save and Carry
11. Lithium battery powered, no need to replace the battery
12. Smart Charging, Safe Charging, Extend Battery life
Principle
The Force Gauge detects push-pull loads through a built-in Sensor, converts mechanical signals into electrical signals, and displays measurement results digitally on the LCD screen after processing. It supports real-time tracking and peak holding two Operating Modes.
Applications
Pushing and pulling force load test, insertion force test, failure test
Steps
1. Power on and select the desired Measurement unit
2. Switch real-time tracking or peak hold mode as needed
3. Set upper and lower qualifying intervals and peak retention times
4. Connect the testing device and fixture
5. Perform push-pull test operation
6. Read the measurement results on the display
7. Charge and save in time after use
Notice
• The working environment should be free of vibration and corrosion medium
• Operating temperature is 0 ℃ -40 ℃, storage temperature is -20~ 70 ℃
• The relative humidity should be kept within the range of 15% -80%
• Charge with a special charger, Charging time is about 4 hours
Avoid use and storage in extreme temperature environments
• Use specialized toolboxes for transportation and storage
