Overview
The electronic constant speed Stirrer is driven by a brushless DC motor, which is suitable for stirring and mixing of low to medium and high viscosity liquids in the laboratory. The machine has a reasonable and compact structure, ultra-low noise and maintenance-free. The stirring Rotation speed is controlled by a microprocessor, which can compensate for the Rotation speed changes caused by load changes and Power supply voltage fluctuations in a timely and effective manner, and the constant speed is reliable. Built-in automatic overload protection device to ensure the safety of continuous operation of the experiment for a long time with high load; stepless adjustment of stirring Rotation speed to meet the correction of stirring Rotation speed at any time in the experiment; digital display setting and actual output stirring Rotation speed to ensure intuitive collection of experimental data; running timing control to ensure that the time of the experiment is effectively controllable, stable stirring Rotation speed, competent for high viscosity medium, Stock stirring.
Features
1. Driven by brushless DC motor, ultra-low noise and maintenance-free
2. Rotation speed controlled by microprocessor, timely compensation for load and voltage fluctuations, constant speed and reliability
3. Built-in automatic overload protection device to ensure long-term high-load continuous operation safety
4. Rotation speed stepless adjustment, Rotation speed can be corrected at any time
5. Digital display settings and actual output Rotation speed, intuitive collection of experimental data
6. Running timing control, time effectively controllable
7. Stable Rotation speed, competent for high viscosity medium and Stock mixing
Principle
The electronic constant speed Stirrer drives the stirring shaft through the brushless DC motor, and the stirring Rotation speed is controlled by the microprocessor, which can timely and effectively compensate the Rotation speed changes caused by load changes and Power supply voltage fluctuations to achieve constant speed stirring. The built-in automatic overload protection device automatically starts when overloaded to ensure the safe operation of the equipment.
Applications
Laboratory low viscosity liquid stirring, laboratory viscosity liquid stirring, laboratory high viscosity liquid stirring, high viscosity medium stirring, Stock stirring
Steps
1. Rated voltage AC100~ 240V, Frequency 50/60Hz
2. Use quick-acting collet to fix stirringrod, clamping range 2-10mm
3. Rotation speed set by capacitive touch keyboard, range 30~ 2000rpm
4. Set timing control, range 1-6000min
5. Start stirring and observe the Rotation speed and status on the TFT display
6. Turn off the power after the experiment
Notice
• Permissible Ambient Temperature not more than 40 ℃
• Allowable relative humidity not more than 80%
• Stirringrod penetration diameter is 8mm at shutdown
Processing capacity is 20L based on water
• Stirring viscosity treatment range is 0-20000 mPa.s
• Avoid overload operation, built-in protection device starts when overload
