Overview
The Defelsko PosiTector 6000 F1 Coating thickness gauge is a universal one-piece probe type Coating thickness gauge, suitable for ferrous metal substrates (such as steel) nonmagnetic coating environment, the measurement thickness range is 0~ 1500 microns. The instrument uses three buttons to operate, menu navigation simplifies use, and the matching rubber protective cover has waterproof, dustproof and oil-proof characteristics to improve the service life.
Features
1. Single-function design, dedicated to ferrous metal substrates and nonmagnetic coatings;
2. Using a monochrome display, it can store 250 readings and support browsing or downloading.
3. Equipped with three buttons and menu navigation, easy to operate.
4. The host is equipped with a rubber protective cover, which has waterproof, dustproof and oil-proof functions;
5. Protection Rating IP65, enhanced durability;
6. Measured data storage capacity of 1000 values;
7. Support Chinese and English system languages;
8. Provide calibrated certificate.
Principle
The PosiTector 6000 F1 Coating thickness gauge is based on the principle of magnetic Induction for measurement of nonmagnetic Coating thickness on ferrous metal substrates.
Applications
Ferrous metal substrate nonmagnetic coating environment
Standards
ISO 2178、ISO 2360、ISO 2808、PrEN ISO 19840、ASTM B499、ASTM D1186、ASTM D1400、ASTM D7091、ASTM E376、ASTM G12、BS3900-C5、SSPC-PA2
Steps
1. Use three buttons and menu-style navigation to operate.
2. Carry out measurements and store data;
3. Browse or download stored readings.
Notice
- Only suitable for ferrous metal substrates and nonmagnetic coating environments;
Make sure the instrument is used in waterproof, dustproof and oil-proof conditions.
- Please refer to the selection suggestion article before use.
- Calibrate and operate according to relevant standards.
