Overview
LANDTEK FM-207-10K Handheld Force Gauge is a small, simple and multi-functional high Accuracy thrust and tension testing instrument, which is widely used in Electronics, Construction Hardware, Light Industry Spinning & Weaving, Auto Parts, Lighters and other ignition devices, fire equipment, pen making, lock making, fishing gear, chemical industry, power machinery, scientific research institutions and other industries. Push-pull load, plug force test, Destructiveness test, etc.
Features
1. High Accuracy and high resolution.
2. Numbers show, ignoring the difference.
3. N (newton), kg (kilogram), lb (pound) three measurement units are available for selection and conversion.
4. Peak hold function. Keep peak display until manually cleared.
5. Data storage function, capable of storing 99 test values.
6. Data output function, data can be input into the computer through data cable or Bluetooth for various analysis.
7. Green and environmentally friendly, it can be set to automatically shut down without operation for 10 minutes; it can also be shut down manually.
8. Can be powered by alkaline battery; can also be connected to 6V DC power supply.
9. Adopt RS-232 data cable output and connect to PC.
10. Provide Bluetooth data output selection.
Principle
The Force Gauge converts physical forces into electrical signals through built-in Sensor measurement of push-pull loads, digitally displays Measured values on a four-digit large LCD screen after processing, supports peak and instantaneous value measurement, and transmits data to a computer through a data output interface for analysis.
Applications
Electronics, Construction Hardware, Light Industry Spinning & weaving, Auto Parts, Lighters and other ignition devices, Fire Equipment, Pen Making, Lock Making, Fishing Tackle, Chemical Industry, Power Machinery, Scientific Research Institutions
Notice
* Working environment: no source and corrosion medium around
* Operating temperature: 0~ 40 ℃
* Allowable relative humidity: < 80%
* Allowable load: 150% F.s (over 110% F.s, there is a beep alarm)
