PUSHEN SHG 20-200 Comb type wet film thickness Gauge, stainless steel unilateral type 20~ 200μm

Name: PUSHEN SHG 20-200 Comb type wet film thickness Gauge, stainless steel unilateral type 20~ 200μm
Brand: Pushen
SKU: NB019512
Price: 107.0 USD
Availability: InStock

$ 107.00Ex works

Made of stainless steel, durable and repeatability; range 20~ 200μm, Division 20μm, step number of teeth 10, unilateral design is convenient for vertical pressing into wet-film measurement, in line with international standards.

Model

Get Quote

Category : Wet Film Thickness Gauge

Brand : Pushen

SKU : NB019512

Service :The delivery and service By NBCLab.Com

Overview

SHG 20-200 comb wet film thickness gauge is a precision measurement tool of PUSHEN brand, which is used for wet film thickness measurement of new painting coatings. The wet film thickness directly affects the painting mass and cost control. The product is made of stainless steel, which is durable and can be used with repeability.

Features

1. Precision stainless steel material, durable, repeatability 2. Measurement unit with high accuracy 3. Five range options available. Measurement range up to 950μm 4. Unilateral design, easy to operate 5. Division is 20μm, the number of teeth is 10, accurate measurement

Principle

The Wet Film Comb is pressed vertically into the wet-film and removed, and the thickness is determined according to the situation where the teeth are infiltrated with the wet-film. The wet film thickness is located at the scale value between the shortest teeth that are infiltrated and the adjacent uninfiltrated teeth.

Standards

GB/T 13452.2、ISO 2808

Steps

1. Select Wet Film Combs with a range similar to the estimated wet film thickness 2. Press the Wet Film Comb vertically into the wet-film 3. Remove the Wet Film Comb from the wet-film 4. Read the scale value between the shortest tooth infiltrated by wet-film and the adjacent uninfiltrated tooth as the wet film thickness

Notice

• Make sure that the Wet Film Comb is pressed vertically into the wet-film during measurement • When selecting the range, it should be similar to the estimated wet film thickness • Correctly read the scale value between the shortest infiltrated tooth and the adjacent uninfiltrated tooth • It should be cleaned and maintained in time after use

Range
20~200μm
Graduation
20μm
number of step teeth
10
shape
Unilateral
material
stainless steel
application standard
GB/T 13452.2、ISO 2808

[Q] Is the price listed on the website the final cost for overseas purchases?

[A] No, it isn't. This is the ex-factory price of the product in the Chinese Mainland. In addition to this price, buyers from different countries need to account for additional costs such as shipping fees, tariffs, and others. For specific regional quotes, please consult our customer service or fill out a quotation form.

[Q] What is the specific process for purchasing the product?

[A] First, please click on the quotation form on the website and fill in detailed information. Our customer service personnel will then send you a quotation based on your specific country and region, confirming payment and delivery methods. Following this, we proceed with contract signing, payment, and shipment. You can then await delivery.

[Q] What should I do if the instrument I purchase needs repair?

[A] After-sales repair for overseas instruments is an unavoidable issue. Our repair terms stipulate that the sender is responsible for the shipping and insurance costs incurred for the repair. Repairs within the warranty period are free, while repair costs beyond the warranty period are determined based on the actual situation.
