TSINGTAO TOKY UM6700 Ultrasonic Thickness Gauge nondestructive detection Large screen backlight

Name: TSINGTAO TOKY UM6700 Ultrasonic Thickness Gauge nondestructive detection Large screen backlight
Brand: TSINGTAO TOKY
SKU: NB040834
Price: 213.0 USD
Availability: InStock

$ 213.00Ex works

Measurement range 1.0~ 300mm, error +/- (0.5% H + 0.1) mm, equipped with large screen backlight display, support sound speed back measurement to improve accuracy, optional a variety of data transmission methods.

Model

UM6700

Get Quote

Category : Ultrasonic Thickness Gauge

Brand : TSINGTAO TOKY

SKU : NB040834

Service :The delivery and service By NBCLab.Com

Overview

The UM6700 Ultrasonic Thickness Gauge is a portable measurement device from the TSINGTAO TOKY brand, which can perform nondestructive Film thickness measurement on various plates, machined parts, pipes and Pressure Vessels, and is widely used in the field of industrial monitoring.

Features

1. Large LCD digital display with high luminance backlight 2. Metric system free conversion function 3. Coupled status prompt function 4. Low battery indicator function 5. Automatic shutdown power saving function 6. Film thickness can be measured back to improve Measurement accuracy 7. Optional RS232/USB/Bluetooth data transfer

Principle

Ultrasonic Thickness Gauge calculates the film thickness of the material by emitting ultrasonic pulses into the material to be tested, and the measurement accuracy can be further improved by using the known Film thickness anti-sound velocity function.

Applications

Petroleum, Chemical, Power Plant, Metallurgy, Shipbuilding, Aviation, Aerospace, Machine Manufacturing, Pressure Vessel, Chemical Equipment Boiler, Oil Storage Tank

Measurement Range
1.0~ 300mm (determined by the probe, special requirements can be customized)
measurement error
±(0.5%n+0.1)
Display resolution
0.1mm
Sound speed Range
500-9000m/s
display screen
Large screen backlit LCD digital liquid crystal display
Operating temperature
0-40℃
Operating humidity
≤90％RH
power supply
4 AA batteries
Host Size
140*60*24mm
weight
185g
Material code
11 groups
