Overview
KESIONOTS KS-OTS-HD800LD low/high temperature test chamber is an environmental test equipment suitable for high temperature and low temperature Reliability test of industrial products. The equipment is used for parts and materials of electronic and electrical, automobile and motorcycle, aerospace, ship weapons, colleges and universities, R & D institutions and other related products under high temperature and low temperature cycle change conditions inspection performance indicators, support product design, improvement, identification and inspection, such as aging test.
Features
1. Temperature range: -20~ 150 ℃.
2. High temperature control accuracy: +/- 1.0 ℃.
3. Using high-quality materials: the studio is stainless steel, and the outer box is high-grade cold plate nano-paint.
4. Efficient insulation: high temperature resistance and high density chlorine-based formic acid vinegar foam insulator material.
5. A variety of refrigeration methods: air, water-cooled/double-stage Compressor.
6. Comprehensive protection device: no fuse switch, Compressor overload protection switch, refrigerant high and low voltage protection switch, ultra-humidity over-temperature protection switch, fuse, fault warning system.
7. Complete accessories: viewing window, 50mm test hole, PL box light, Shelf, wet and dry ball gauze.
8. High-performance controller: Korean or Japanese "OYO" brand optional.
9. Reliable refrigeration system: French "Taikang" brand or German "BITZER".
Principle
The low/high temperature test chamber precisely adjusts the temperature in the box through the control system to achieve high temperature and low temperature environment simulation. In aging tests such as promoting the deterioration of sulfur-added rubber, the product performance is evaluated by calculating the tensile force and elongation change rate before and after heating. For example, one day of testing at 70 ° C is theoretically equivalent to 6 months of exposure to the atmosphere.
Applications
Electronics and electricians, automobiles and motorcycles, aerospace, ships and weapons, colleges and universities, R & D institutions
Standards
GB10592-89、GB2423.1、GB2423.2、GJB150.3、GJB150.4、IEC、MIL
Steps
1. Connect power supply: Select 220VAC +/- 10% 50/60Hz or 380VAC +/- 10% 50/Hz power supply according to specifications.
2. Set parameters: Set the required Temperature range and Miscellaneous test conditions through the controller system.
3. Start the equipment: Open the test chamber to monitor temperature changes and performance indicators.
4. Test: inspection of product parts and materials under high temperature and low temperature cycle conditions.
5. End the test: Turn off the equipment, record the data, and analyze the results.
Notice
• Power supply voltage meets specifications to avoid overload.
• Regularly check the protection devices such as fuse switch and Compressor overload protection switch to ensure normal operation.
• Monitor Temperature Fluctuation and Uniformity during the test to prevent ultra-temperature and ultra-humidity.
• When using accessories such as wet and dry ball gauze, pay attention to maintenance and replacement to ensure accuracy.
• Avoid frequent switching during equipment operation to prolong service life.
