Overview
KESIONOTS KS-OTS-HD408LD low/high temperature test chamber, also known as environmental test chamber, is suitable for high temperature and low temperature Reliability test of industrial products. The equipment is used for parts and materials of electronic and electrical, automobile and motorcycle, aerospace, ship weapons, colleges and universities, R & D institutions and other related products to inspect various performance indicators under high temperature and low temperature (alternating) cycle changes, and support product design, improvement, identification and inspection, such as aging test.
Features
1. With a wide temperature control range, the performance index meets the national standard GB10592-89.
2. Applicable to GB 2423.1, GB 2423.2 standards for low temperature, high temperature and constant temperature test.
3. Equipped with a variety of protection devices, including no fuse switch, Compressor overload protection switch, refrigerant high and low voltage protection switch, ultra-humidity over-temperature protection switch, fuse and fault warning system.
4. Adopt high-quality components, such as Korean or Japanese "OYO" brand controllers, French "Taikang" brand or German "BITZER" refrigeration systems.
5. Provide a variety of accessories, including viewing window, 50mm test hole, PL box light, Shelf, wet and dry ball gauze.
Principle
The low/high temperature test chamber realizes temperature control through the refrigeration system and heating system, and simulates the high temperature and low temperature environment inside the studio. The equipment adopts air and water-cooled/double-stage Compressor for refrigeration, combined with high temperature resistance and high density chlorine-based formic acid vinegar foam insulator material insulation to ensure temperature uniformity and Stability. The controller system precisely adjusts the temperature change and supports alternating cycle testing.
Applications
Electronics and electricians, automobiles and motorcycles, aerospace, ships and weapons, colleges and universities, R & D institutions
Standards
GB10592-89、GB2423.1、GB2423.2、GJB150.3、GJB150.4、IEC、MIL
Steps
Connect the power supply to ensure that the voltage meets the requirements (1 220VAC +/- 10% 50/60Hz or 3 380VAC +/- 10% 50/60Hz).
2. Temperature range (-20~ 150 ℃) and test parameters are set by the controller system.
3. Start the equipment, start the cooling and heating systems, and monitor temperature changes.
4. Place test samples in the studio and observe performance indicators.
5. After the test is completed, turn off the device and disconnect the power.
Notice
• Power supply voltage within the specified range to avoid overload.
• Regularly check the protection device, such as no fuse switch and Compressor overload protection switch, to ensure that the function is normal.
• Monitor Temperature Fluctuations during testing to prevent over-temperature or over-humidity.
• When using wet and dry bulb gauze, make sure it is clean and installed correctly.
• During the operation of the equipment, do not switch frequently to avoid affecting the life of the Compressor.
