Overview
KESIONOTS KS-OTS-HD1000LD low/high temperature test chamber is suitable for high temperature and low temperature Reliability test of industrial products. It is used for product design, improvement, identification and inspection of various performance indicators for parts and materials of related products such as electronics and electricians, automobiles and motorcycles, aerospace, ship weapons, colleges and universities, R & D institutions, etc. The product has a wide temperature control range, and the performance indicators meet the technical conditions of the national standard GB10592-89 low/high temperature test chamber.
Features
1. Temperature range: -20~ 150 ℃
2. High temperature resolution accuracy: +/- 0.1 ℃
3. Temperature Uniformity: +/- 1.0 ℃
4. High temperature control accuracy: +/- 1.0 ℃
5. Temperature Fluctuation: +/- 0.5 ℃
6. Fast heating rate: Technologies 4.0 ℃/min
7. Cooling rate: Technologies 1.0 ℃/min
8. The studio material is stainless steel, and the outer box material is high-grade cold plate nano-paint.
9. The thermal insulation material is made of high temperature and high density chlorine-based formic acid vinegar foam insulator material
10. The refrigeration system adopts air and water-cooled/double-stage Compressor
11. Equipped with a variety of protection devices: no fuse switch, Compressor overload protection switch, refrigerant high and low voltage protection switch, ultra-humidity over-temperature protection switch, fuse, fault warning system
12. Complete accessories: viewing window, 50mm test hole, PL box light, Shelf, wet and dry ball gauze
13. The controller system can be selected with Korean or Japanese "OYO" brand
14. The refrigeration system adopts the French "Taikang" brand or the German "BITZER" brand.
15. Power supply voltage adaptability: 1 220VAC +/- 10% 50/60Hz & 3 380VAC +/- 10% 50/60Hz
Principle
The low/high temperature test chamber realizes temperature control through the refrigeration system and the heating system. When promoting the deterioration of the sulfurized rubber, the rate of change of tensile force and elongation before and after heating is calculated. It is generally considered that the test at 70 ° C for one day is theoretically equivalent to exposure to the atmosphere for 6 months. The performance test of the product in the high temperature, low temperature (alternating) cycle change environment is realized through the precise temperature control system.
Applications
Electronics and electricians, automobiles and motorcycles, aerospace, ships and weapons, colleges and universities, R & D institutions
Standards
GB10592-89、GB2423.1、GB2423.2、GJB150.3、GJB150.4、IEC、MIL
Steps
The information does not mention the specific operation steps
Notice
The information does not mention specific precautions
