Overview
The automatic imager (model NBC-YX-4030ZD) adopts the digital Measuring method to convert the shape of the measured object to the computer through image acquisition, and uses professional measurement software for size measurement. Compared with the Optical inspection projection magnification Measurement mode of traditional projectors, this instrument is mainly used for the detection, positioning, evaluation and diagnosis of various defects inside the workpiece (such as welds, crazing, inclusions, pores, etc.), suitable for laboratories and engineering sites.
Features
1. Adopt all-marble structure (High Accuracy "Jinan Green" natural granite is used for the base, column and workbench), with high Stability, rigidity and corrosion resistance.
2. Strengthen Product Structure and Appearance Design, Focus on Software Function Practicality and Stability, Provide High Cost Performance.
3. Three-axis friction precision transmission, sensitive and reliable, no backlash and fast movement.
4. Optical inspection system and high resolution CCD ensure clear measurement picture.
5. Adjustable LED annular surface Illuminant to achieve large-angle illumination and avoid thermal deformation of the workpiece.
6. Optical inspection ruler and data processing by the digital measurement and data processing system.
Principle
The two-dimensional image measurement instrument collects and converts the shape image of the measured object to the computer through the digital Measuring method, and uses professional measurement software for size measurement and analysis.
Applications
Boiler, Pressure Vessel, Aerospace, Aviation, Electric Power, Petroleum, Chemical Industry, Offshore Oil, Pipeline, Military Industry, Shipbuilding, Automobile, Machinery Manufacturing, Metallurgy, Metal Processing Industry, Steel Structure, Railway Transportation, Nuclear Power, Universities
